Sample work

Complete sets, not screenshots

Every sheet below was drawn by Clearline Design to show how we draw. None of it is client material, so there is nothing confidential in any of it, and every sheet is marked not for construction. Open a set and judge the drawings. We draw your packages, and every package we draw we look for what repeats; when we find it we build the tool and the next package costs less.

Structural steel sample set, sheet S-001: cover sheet with general notes and bill of material Structural steel sample set, sheet B-201: beam B1 piece detail and beam end connection

Structural steel

6 sheets · PDF · 350 KB

Six sheets: cover and BOM, framing plan, beam details, column and base plate, typical connections, joist bearing. A framed mezzanine, set up the way any structural or miscellaneous steel package would be.

  • Framing plan with piece marks
  • Beam, column and base plate piece details
  • Bolt schedule and anchor rods
  • Bill of material tied to the detail marks
  • AISC 360 and AWS D1.1 general notes
Open the set (PDF) →
Stair and rail sample set, sheet MS-101: erection plan, stair elevation and section at mid flight with piece marks Stair and rail sample set, sheet MS-102: stringer, post and tread piece details with shop weld symbols

Miscellaneous steel: stair & rail

3 sheets · PDF · 1692 KB

A straight-run steel stair, twelve feet floor to floor, with a guard and a pipe handrail. Miscellaneous metals is most of what a fabrication shop actually buys drawings for, and it is detailed differently from structural framing.

  • Erection plan and elevation with piece marks and a north arrow
  • Stringer, post and tread piece details with copes, holes and shop welds as symbols
  • Partial guard elevation covering rails, handrail and brackets
  • Bolt schedule with size, grade, quantity and hole type
  • Bill of material reconciling to the marks — the count a price is quoted on
Open the set (PDF) →
Stone countertop sample set, sheet 1: cover sheet with scope and material schedule Stone countertop sample set, sheet ST-02: piece details with fabrication dimensions and piece schedule

Stone & solid surface

5 sheets · PDF · 334 KB

A kitchen in engineered quartz, laid out the way a shop needs to cut it. Same approach for any countertop or solid surface work.

  • Plan with seam locations and cutouts
  • Piece details with fabrication dimensions
  • Edge profiles and waterfall detail
  • Island elevation and support brackets
  • Piece schedule and scope exclusions
Open the set (PDF) →
Casework sample sheet CW-101: break room cabinet elevation, plan, three sections and schedules Detail from the same sheet CW-101: casework schedule, material and finish legend, and hardware schedule showing the basis for each count

Casework & millwork

1 sheet · PDF · 835 KB

A break room cabinet run drawn to AWI custom grade, on one dense sheet. Everything a shop needs to cut and build it, with the counts it would be quoted from.

  • Elevation and plan with cabinet marks and door swings
  • Sections at door base, drawer base and sink base
  • Counter edge detail at full size
  • Casework schedule with the unit count a price is quoted on
  • Hardware schedule showing the basis for every count
  • Material and finish legend
Open the set (PDF) →
Generated quantities sample set, sheet P-101: plan with edge schedule by profile Generated quantities sample set, sheet P-201: piece details with square footage and cutouts

Generated quantities & nesting

3 sheets · PDF · 100 KB

Output sheets from the casework and countertop pipeline. To see the stages, there is a pipeline walkthrough.

  • Edge schedule by linear foot, per profile
  • Piece details with square footage
  • Slab layout with kerf and the retained remnant
Open the set (PDF) →
Block library sample set, sheet L-001: annotation blocks drawn at plot size Block library sample set, sheet L-003: steel detailing pack with sections, marks and weld symbols

Standards & block library

3 sheets · PDF · 128 KB

The reusable content behind the sets above, and the reason a second package looks exactly like the first.

  • Annotation blocks drawn at plot size
  • Detail bubbles, section marks, rev tags
  • Cutout, faucet and bracket blocks at real size
  • Steel sections, member marks and weld symbols
Open the set (PDF) →
Working to your standards instead of ours is normal. Send your title block, layer standard and a set of your existing drawings, and the work comes back looking like yours rather than like ours. That is usually the first thing we set up on a new account.
The casework pipeline has a walkthrough too. The pipeline walkthrough steps through the sequence: an interior elevation and a bid go in, and a built model, a dimensioned drawing set and a panel-level cut list come out, reviewed by a drafter before it ships.
